Handheld Drone Detector with 3KM Detection Range, Spectrum Feature Identification, and Multi-Alarm System

Handheld Drone Detector with 3KM Detection Range, Spectrum Feature Identification, and Multi-Alarm System

Brand Name:	MYT
Model Number:	PMJ8
MOQ:	1
Price:	Pricing is negotiable based on order quantity
Delivery Time:	5 work days
Payment Terms:	TT,LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS、CMA、CAL、ILAC-MRA

Document:

Product Brochure PDF

Detection Range:

3KM

Detection Principle:

Spectrum Feature Identfication

Idengtification Type:

Most Mainstream Brand Drones And FPV Drones

Intercom Distance:

3KM（open And Unobstructed）

Detection Frequency:

Supports 400MHz-6GHz Customized Scanning，by Default 400MHz，800MHz，900MHz，1.2GHz，1.4GHz，2.4GHz，5.2GHz，5.8GHz

Detection Response Time:

≤3S

Alarm Method:

Audio，vibration，light

Working Temperature:

-20℃~+50℃

Battery Life:

Main Device≥8 Hours，auxiliary Device≥12 Hours

Endurance Time:

6hours

Data Transportation:

1KM+

Power Supply:

Battery

Supply Ability:

1000units per month

Highlight:

6ghz handheld drone detector

6ghz portable drone detector

1.2ghz handheld drone detector

Product Description

Anti Drone Radio Detection Handheld Device Long Range Detector

Product Introduction

This advanced handheld drone detection equipment features two scanning modes: full-band scanning and key-band scanning. It contains the industry's most comprehensive database of drone models and their operational frequencies, enabling precise identification of various drone types.

The system achieves an extremely low false alarm rate in complex electromagnetic environments and can accurately detect quadcopters, fixed-wing aircraft, DIY drones, FPV drones, and other unmanned aerial vehicles, generating sound, light, and vibration alerts upon detection.

Equipped with a LoRa interface, the device can transmit detected drone data to other anti-drone systems via LoRa modules, facilitating coordinated counter-drone operations.

Testing & Operation Principle

Test Objective: Verify equipment detection range exceeding 3KM.

Detection Principle: The device detects video transmission signals emitted by drones.

Technical Note: Video transmission (VT) signals are emitted by drones, with drone controllers serving as receiving units. For verification, both the handheld detector and remote controller must be positioned within the same video range. The detected frequency range of 5700MHz-5800MHz represents standard VT signal bands, confirming that drone controllers do not emit signals.

Key Features

Dual-mode detection: Spectrum power detection and spectrum characteristic matching detection modes
Comprehensive model detection: Accurate identification of mainstream brands including DJI, Autel, Hubsan, and most FPV/DIY drones
Wide frequency coverage: Full spectrum coverage from 70MHz-6.2GHz with 8-12 key detection bands
Advanced FPV early warning: Unique baseband signal analysis technology for rapid DIY and FPV drone detection
Low false alarm rate: Spectrum signal detection minimizes false alarms in complex electromagnetic environments

Technical Specifications

Display Content	Description
Detection Status	Shows device detection status and signal type
Alarm Functions	Red light, vibration, and sound alarm indicators with on/off status
Frequency Display	Detection signal frequency and strength indicators
Identification Types	Most mainstream brand drones and FPV drones
Detection Frequency	400MHz-6GHz custom scanning; default bands: 400MHz, 800MHz, 900MHz, 1.2GHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz
Detection Range	≥2KM
Response Time	≤3 seconds
Detection Principle	Spectrum feature identification
Alarm Methods	Audio, vibration, light
Communication Range	3KM (open and unobstructed)
Battery Life	Main device ≥8 hours, auxiliary device ≥12 hours
Operating Temperature	-20℃ to +50℃

After-Sales Service

24/7 customer service and technical support
Online technical support for usage or quality issues with comprehensive problem diagnosis
3-month return policy from dispatch date for unsatisfactory products (undamaged items eligible for full refund or product modification discussions)

Business Partnerships

African Parks Counter-UAV Strategic Partnership

Certifications

Company Profile

Chongqing Miao Yitong Technology Co., Ltd. specializes in anti-drone and unmanned intelligent defense management systems. Supported by the AI Internet of Things Research Institute of the Chinese Academy of Sciences and collaborations with multiple intelligent AI companies, the company maintains advanced research laboratories for AI unmanned field products with numerous technical patents.

Our products provide comprehensive unmanned automatic management solutions for defense and perimeter security applications, including AI anti-drone systems and AI unmanned vehicle patrol systems. These integrated systems incorporate optoelectronics, radar, vibration detection, thermal imaging, facial recognition, and radio frequency management technologies, delivering 24/7 uninterrupted anti-drone defense and ground perimeter security warning systems.

Our solutions help clients reduce costs, optimize human resource allocation, and ensure life and property safety. The exceptional security systems have earned the company an excellent reputation and created significant value for our partners.
