Portable Handheld Drone Detector Defense Individual Used Drone Detection Device DR400A

 Portable Handheld Drone Detector Defense Individual used dronedetection device DR400-A


1, Device Overview

  The handheld drone detection device integrates spectrum sensing technology and can effectively detect and identify various types of drones. The device adopts self-developed low-power ultra-wideband digital receiving technology, signal detection algorithm and advanced drone identification algorithm, and is connected with an efficient ultra-wideband antenna. It can achieve an extremely low false alarm rate in complex electromagnetic environments and can accurately identify quadcopter, fixed wing, DIY drones, FPV drone etc., and generate sound, light and vibration alarms.

2, Device Features

1) Dual-mode detection:

Switching between spectrum power detection mode and spectrum characteristic matching detection mode

2) Wide range of detection models:

Accurately identify drones of mainstream brands such as DJI, Autel, and Hubsan, and most FPV and DIY drones, etc.

3) Wide coverage of detection frequency bands:

Full coverage of mainstream frequency bands 70MHz-6.2GHz, 8-12 key detection frequency bands;

4) Super FPV early warning:

Unique baseband signal analysis and identification technology, rapid early warning for all types of DIY and FPV drones;

5) Low false alarm rate:

Spectrum signal detection can reduce the false alarm rate and achieve extremely low false alarm rate in complex electromagnetic environments;

Test Objective:

To verify if the equipment has a drone detection range of over 3KM.Principle of the Device:The device detects the video transmission signals emitted by drones.

TIPS:The video transmission (VT) signal is emitted by the drone, and the drone controller serves as the receiving unit for the VT signal. To verify the authenticity of the video, it is necessary to place both the handheld detection device and the remote controller in the same video. The detected frequency range in the video is 5700MHz-5800MHz, which is a standard VT signal frequency band. Therefore, the drone controller does not emit signals.

3, Functional highlight


1) Passive detection: Does not emit electromagnetic signals actively, environmentally friendly with high concealment

2) 360° Full frequency band detection: Supports scanning and detection of customized frequency bands of full frequency

3) Super early warning for FPV drones: Unique baseband signal analysis and identification technology, super early warning capability for FPV drones, suitable for most consumer drones and assembled FPV drones

4) Comprehensive early warning: Supports sound, light, vibration, and voice alarms, and displays information such as drone type, frequency, and predicted distance in real time

5) Early warning of threat level of the target: Provides early warning of the target distance through changes in sound frequency

6) Work around the clock: Military quality, autonomous work, and long battery life

5, After-Sales service
Lifetime free model library upgrades, profesdional 24/7online service, customizable colors and languages.

6, Certification Certificate

7, Company profile

  Chongqing Miao Yitang Technology Co., Ltd. is a specialized company engaged in anti-drone and unmanned intelligent defense management.

  With the technical support from the AI Internet of Things Research Institute of the Chinese Academy of Sciences and collaborations with multiple intelligent AI companies, the company has established research laboratories for AI unmanned field products, accumulating a variety of technical patents.

  The company's products are widely applied to unmanned automatic management solutions for various defense and perimeter areas, including AI anti-drone systems and AI unmanned vehicle patrol systems. These systems integrate with multiple technologies such as optoelectronics, radar, vibration, thermal imaging, facial recognition, and radio frequency management, truly achieving a 24-hour uninterrupted anti-drone defense and ground perimeter defense warning system. This allows for cost savings for clients, reduction in human resource allocation, and ensures the safety of clients' lives and property. The outstanding security system has won the company an excellent reputation and created higher value for its partners.

8, Paking and Delivery

  Supports various logistics methods including shipping, air freight, water transport, and express delivery, covering logistics in 90% of the global regions.
