MYT technology: Global Intelligent Security Expert
| Place of Origin: | China |
|---|---|
| Brand Name: | MYT |
| Model Number: | DR400B |
| Document: | Product Brochure PDF |
| Minimum Order Quantity: | 1 units |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000units per month |
| Highlight: | smart perimeter defense system,perimeter defense system early warning,smart perimeter defense security |
||
|---|---|---|---|
Smart Perimeter Defense System-Microwave Radar Early Warning Vibration Intrusion Detection System DP200-1
1, Product Introduction
The system integrates microwave radar detection and MEMS vibration detection intrusion technologies within a single detector node. Through the microwave sensing function of the microwave radar vibration fusion detector, it provides a pre-alarm for intrusion activities. When actions such as climbing, crossing, or damaging occur, the system can trigger an alarm and accurately locate the site of the incident, with a positioning accuracy of 0-6 meters.
2, System Composition
① DP200T-1
Microwave Radar Early Warning Vibration Intrusion Detector
② DP200Z-1
Microwave Radar Vibration Intrusion Detection Master Unit
3,System Introduction
Perimeter intrusion prevention system is a technical measure to control the undisclosed management and secure perimeter area.
4, Management Platform
5, Specification
① DP200T-1
Microwave Radar Early Warning Vibration Intrusion Detector
| DP200T-1 Specification (● yes, ○ no) | ||
| Detection Method | Dual Fusion Detection of Microwave Radar Early Warning and MEMS Vibration Detection | ● |
| Maximum Detection Range of Microwave Radar | 10m | ● |
| Microwave Radar Frequency | 24GHz±10MHz | ● |
| Microwave Radar Range Measurement Accuracy | 10cm | ● |
| Effective Distance of Vibration Detection | 0-6m | ● |
| Relative Humidity | ≤95% | ● |
| Protection Level | IP68 | ● |
② DP200Z-1
Microwave Radar Vibration Intrusion Detection Master Unit
| DP200Z-1 Specification (● yes, ○ no) | ||
| Installation Method | Fence Wall Mount | ● |
| Data Communication | RS-485 | ● |
| Operating Temperature | -55℃ to +85℃ | ● |
| Operating Voltage | 24VDC | ● |
6, After-Sales service
Lifetime free model library upgrades, profesdional 24/7online service, customizable colors and languages.
