Drone MX680
1, Product Introduction
MX680 flight platform for various application environments, aiming to improve the feasibility of Isborh Tor aerial operations. The MX680 series has a compact design, all-in-one carbon fiber, 680mm ultra-small wheelbase, up to 90 minutes (no payload) battery life, open source protocol, FPV, can be matched with a variety of mounts, adapt to various environments and scenarios. For multiple industries, provides professional solutions.
2, Functional highlight
① Carbon fiber One-piece body
② 90 minutes battery life (no payload)
③ Ultra-long transmission distance
④ Multi-load platform
3, Specification
| MX680 specifications | |
| Model | MX680 |
| Number of axes | 4 |
| Symmetrical motor wheelbase | 680mm |
| Maximum ascending speed | 3m/s |
| Drone unfolded size | 980*980*255mm |
| Maximum descent speed | 2.1m/s |
| Drone folded size | 544*544*255mm |
| Maximum withstand wind speed | 10m/s |
| Net weight | 1200g |
| Flight time (no payload) | 90 minutes |
| Shipping size | 630*620*340mm |
| Flight time (1KG payload) | 60 minutes |
| Packing weight | 10KG |
| Power system | Motor 4008 ESC 40A |
| Recommended maximum take-off weight | 3.5KG |
| Operating ambient temperature | -10°C to 40°C |
| Hovering accuracy | Vertical ± 0.8m/ Horizontal ± 2.5m |
| Maximum flight speed | 54Km/h |
| Maximum cruising range | 35KM |
| Maximum pitch angle | 20° |
