MYT technology: Global Intelligent Security Expert
| Place of Origin: | China |
|---|---|
| Brand Name: | MYT |
| Model Number: | MX680 |
| Document: | Product Brochure PDF |
| Minimum Order Quantity: | 2 units |
| Delivery Time: | 10 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10000units per month |
| Highlight: | 54km/h 10kg payload drone,10kg payload drone 5km,54km/h heavy payload drone |
||
|---|---|---|---|
Drone MX980
High precision 10KG load 5KM range multiple people view Bottom lighting Loudspeaker Laser obstacle avoidanc MX980
1, Product Introduction
MX680 flight platform for various application environments, aiming to improve the feasibility of Isborh Tor aerial operations. The MX680 series has a compact design, all-in-one carbon fiber, 680mm ultra-small wheelbase, up to 90 minutes (no payload) battery life, open source protocol, FPV, can be matched with a variety of mounts, adapt to various environments and scenarios. For multiple industries, provides professional solutions.
2, Functional highlight
① High precision RTK
② Max load capacity of 10KG
③ 5KM working range
④ Support for multiple people to view
⑤ 4G dual datalink
⑥ Bottom lighting
⑦ Loudspeaker
⑧ Laser obstacle avoidanc
3, Specification
| MX980 specifications | |
| Number of axes | 4 |
| Symmetrical motor wheelbase | 910mm |
| Maximum ascending speed | 3m/s |
| Drone unfolded size | 1218*1167*282mm |
| Maximum descent speed | 2.1m/s |
| Drone folded size | 346*421*282mm |
| Maximum withstand wind speed | 10m/s |
| Maximum pulling force | 12KG/axis |
| Operating ambient temperature | -20°C~50°CC |
| Take-off weight | 3-5kg/axis |
| Maximum flight speed | 54km/h |
| Hovering accuracy | Vertical ±0.8m, Horizontal ±2.5m |
| Maximum pitch angle | 20° |
| Maximum cruising range | 35km |
| Maximum allowable voltage | 52.2V |
