Portable Drone Detector with 12KM Detection Range and Real-Time Video Interception for Public Security

• Device Dimensions: Approximately 343mm × 230mm × 86mm (L × W × H)
• Battery: Removable, with a capacity of 25Ah; dimensions 65mm × 73mm × 148mm
• Upgrade Interface for Additional Boards (USB)
• Charging Interface (using a special aviation plug structure)
• Waterproof Design of Device Structure, IP66 rating
• GPS positioning function
• Tablet mounting function; supports the use of a tablet mounted on the device
• Supports multiple usage forms including backpack, fixed, and vehicle-mounted
• The backpack has compartments for antennas and tablet storage
• Battery level display function (Coulomb counter)
• RJ45 networking function
• Built-in 4G network function (both international and domestic)

• Alarm Signal Reception: The tablet provides an audible alarm signal upon receiving an alarm from the host device (can be manually disabled)
• Drone Localization: Capable of locating the position of drones
• Pilot Localization: Capable of locating the position of the drone operator
• Unique Serial Number: Can identify the unique serial number of drones
• Whitelist and Blacklist: Drones with unique serial numbers can be added to a whitelist; the system will automatically alarm when drones not on the whitelist are detected
• Trajectory Tracking: Can display multiple drone flight trajectories simultaneously
• Electronic Map: Features both online and offline electronic map capabilities
• Trajectory Playback: Capable of replaying flight trajectories
• Historical Record Query: Allows for querying and downloading of historical records (detection logs)
• Navigation Spoofing Interface: Equipped with a reserved interface for navigation spoofing
• Operation Mode: Supports both local and cloud deployment (with future upgrade to cloud)
• Multi-Device Access: Capable of supporting access from multiple devices
• Real-Time Video Viewing: Capable of displaying real-time video feeds

The portable drone detection and positioning device integrates functions such as detection, drone and pilot positioning, video interception, and video storage. It is capable of full-band detection, drone and pilot positioning, FPV analog video transmission detection, video interception, display and control, and video storage.

In complex electromagnetic environments, it can accurately identify various types of drones, including quadcopters, fixed-wing drones, DIY drones, and FPV drones, and generates audio, visual, and vibration alerts. This device is applied in various scenarios such as daily patrols, protection of important targets, team operations, and evidence collection.

• Full-Band Detection: Covers the full frequency band from 70 MHz to 6.2 GHz
• FPV Band Coverage: Complete coverage of analog video transmission from 300 MHz to 6.2 GHz
• Precision Positioning: Monitors multi-dimensional information of drones, including location (latitude and longitude, azimuth), speed, flight path, and remote controller position (latitude and longitude, azimuth)
• Video Interception: Capable of intercepting all analog video transmissions to analyze FPV intrusions and real-time dynamics from the "first-person perspective"
• Superior Detection Capability: Detection and decryption range can reach up to 12 km
• Multi-End Alarm Push: Pushes alarm information to multiple mobile devices, enabling team collaboration and efficient response
