DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start

DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start
DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start
DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start
Basic Information
Place of Origin: China
Brand Name: MYT
Certification: CNAS、CMA、CAL、ILAC-MRA
Model Number: DY-150P
Document: MYT User Manual.pdf
Minimum Order Quantity: 1
Price: ＄5,720
Payment Terms: L/C,T/T
Supply Ability: 1000units per month
Get Best Price Chat Now
Power Adapter Param- Eters: Input Voltage 100-240V/AC 50-60Hz, 160W; Output Voltage 24V/DC Weight Of The Main Body: 4.4 Kg (excluding Lithium-ion Batteries); 4.8 Kg (including Lithium-ion Batteries)
Software Function: Supports Self-check And Calibration; Provides Real-time Data Storage, Retrieval, And Export Capabilities With A Storage Capacity Of At Least 1 Million, And Allows Data Addition. Dimensions Of The De- Tector (mm): 430 Long × 190, High × 180, Wide
Battery Settings: Voltage: 21V, Capacity: 6400mAh, Can Power The Detector Continuously For More Than 3 Hours, Standby Power Supply Is ≥8 Hours Source: Power Adapter/lithium-ion Battery Pack Power
Data Interface: Has A USB Port Work Environment: -5℃ To 55℃, With Relative Humidity ≤93%RH And Non-condensation
Highlight:

explosive trace analyzer with photoionization

,

narcotic trace analyzer high-resolution

,

anti UAV radar detection system

DY-150P Portable Trace Explosive and Drug Detector

1,Overview

  The DY-150P Portable Explosive and Drug Detector represents a new generation of trace detection and analysis instruments developed by MYT Technology Co., LTD. Utilizing advanced photoionization high-resolution ion mobility spectrometry technology, this device offers superior security screening capabilities without radioactive components, ensuring safe operation for all users.

2,Key Features

Can detect 6 types of explosives TNT (TNT), RDX (RDX), PETN (PETN)
Nitroglycerin (NG), nitrate-based explosives (ammonium nitrate, AN), and black powder (sulfur, BP) may also be mixed with prohibited substances as required by users.
Core technology Non-radioactive photoionization high-resolution ion mobility spectrometry (PIMS)
Sample mode Wipe and sample
Sensitivity Nak class (ng, 10-9 g)
Alarm method Sound + display sample information + color indicator light
Parsing time <5 seconds (s)
Cold start time <15 minutes (min)
False positive rate ≤ 1%
Display screen 3.5 TFT color LCD touch screen
Relevance ratio ≥99%
Tyrant detection limit <1 nanogram (ng)
Overload recovery time ≤1 minute (min)
Probe mode switching time ≤10 minutes (min)

3,Technical Specifications

Work environment -5℃ to 55℃, with relative humidity ≤93%RH and non-condensation
Software function Supports self-check and calibration; provides real-time data storage, retrieval, and export capabilities with a storage capacity of at least 1 million, and allows data addition.
Data interface Has a USB port
Wi-Fi function It supports remote monitoring of detector operation status and remote downloading of alarm data
Source Power adapter/lithium-ion battery pack power
Power adapter parameters Input voltage 100-240V/AC 50-60Hz, 160W; output voltage 24V/DC
Battery Settings Voltage: 21V, capacity: 6400mAh, can power the detector continuously for more than 3 hours, standby power supply is ≥8 hours
Dimensions of the detector (mm) 430 Long * 190, High * 180, Wide
Weight of the main body 4.4 kg (excluding lithium-ion batteries); 4.8 kg (including lithium-ion batteries)

4,Applications

  • Airports and transportation hubs
  • Subways, ports, and border crossings
  • Hotels, churches, and commercial centers
  • Large gatherings and public events
  • Educational and research institutions

5,Working Principle

  The detector employs next-generation ion mobility spectrometry technology. Sample molecules undergo thermal desorption, enter the ionization zone, and are ionized by a non-radioactive source. Charged ions migrate through an electric field to the ion reception zone, converting to electrical signals that form a detection spectrum. Different ions exhibit distinct migration rates, enabling identification of specific substances.
DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 0
  This advanced technology ensures reliable detection of trace explosives and drugs, making the DY-150P an essential tool for modern security operations.

6, Application Scenarios

DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 1


7, Certification Certificate

DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 2DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 3DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 4DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 5DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 6DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 7DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 8DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 9DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 10DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 11DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 12DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 13


8, Company profile

 Chongqing Miao Yitang Technology Co., Ltd. is a specialized company engaged in anti-drone and unmanned intelligent defense management.

 With the technical support from the AI Internet of Things Research Institute of the Chinese Academy of Sciences and collaborations with multiple intelligent AI companies, the company has established research laboratories for AI unmanned field products, accumulating a variety of technical patents.

 The company's products are widely applied to unmanned automatic management solutions for various defense and perimeter areas, including AI anti-drone systems and AI unmanned vehicle patrol systems. These systems integrate with multiple technologies such as optoelectronics, radar, vibration, thermal imaging, facial recognition, and radio frequency management, truly achieving a 24-hour uninterrupted anti-drone defense and ground perimeter defense warning system. This allows for cost savings for clients, reduction in human resource allocation, and ensures the safety of clients' lives and property. The outstanding security system has won the company an excellent reputation and created higher value for its partners.

DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 14DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 15DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 16DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 17DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 18DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 19


7, Customer Service

1). We offer 24 hours service after sales

2). If there are any usage or quality issues with the product, we provide online technical support to diagnose the cause of the problem.

3). Should you find the products unsatisfactory, kindly return it to us within a period of 3 months from the date of dispatch. Upon receipt and inspection, should the products be found to be free from any damage attributable to human factors, a full refund will be granted. Alternatively, we can engage in discussions to amend the product and subsequently reship the product to you.

DY-150P Portable Trace Explosive and Drug Detector with Nak Class Sensitivity, <5 Seconds Parsing Time, and <15 Minutes Cold Start 20
